Mobile Hydraulic Drill Rig For Hard Rock To 350m Depth XH350
350m deep hole construction, mobile water well drilling rig, multifunctional hydraulic water well drilling rig, underground rock drilling equipment
5.0
Product Series:
XH350
Brand:
Xinhao
Customization:
Customized according to customer needs
Application:
Deep water wells, geothermal wells, irrigation wells, etc., especially suitable for water conservancy projects in mountainous areas and rocky strata
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Product Introduction
When tackling deep well projects, are you concerned about equipment lacking power or wearing out too quickly due to depth and hard formations, leading to project delays and cost overruns? The XH350 Crawler Water Well Drilling Rig ensures worry-free operation for you. It not only boasts a drilling capacity of 350 meters but also features an exceptionally large torque of 9700 N·m and core components from top-tier brands, guaranteeing outstanding stability and wear resistance in deep hole drilling.
We understand that each project's geology and budget are unique. That's why we offer professional customization services – simply inform us of your specific construction conditions, and we will match you with the most suitable rig configuration, providing a reliable one-stop solution.
Our advantage
350m Deep Drilling Capacity
Drilling depth and efficiency are directly critical to project success. The XH350 Water Well Drilling Rig, with its rated drilling depth of 350 meters and rotary torque of 9700 N·m, easily handles various hard and complex formations. Coupled with a wide speed range of 45-115 rpm, you can flexibly match the drilling speed and torque to the actual geology, maximizing efficiency. This means it delivers ample and reliable power, whether for deep bedrock water extraction or large-scale irrigation projects, effectively solving the core pain points of "inability to penetrate" and "slow drilling speed".
Robust Structure & Durable Equipment
The durability and stability of your water well drilling equipment determine your long-term operating costs. The XH350 is comprehensively upgraded in its key components: a 24-ton hoisting capacity and a 6.6-meter mast stroke ensure efficient handling of heavy drill pipes. More importantly, we have reinforced the core parts essential for deep hole operations, with wear resistance and stability far exceeding ordinary industry standards. This significantly reduces failure rates and maintenance frequency. Powered by a 91KW Weichai engine, the rig ensures smooth power output and maintains excellent reliability even under prolonged, high-intensity workloads.
Your Exclusive Drilling Solution
We believe there is no single "best" equipment, only the most suitable solution. The XH350 Crawler Water Well Drilling Rig offers multiple configuration options, including drill pipe diameters (89/102 mm) and working air pressure (1.7-3.3 MPa). You don’t need to be an expert – simply provide your geological conditions and construction requirements, and our professional team will recommend the optimal configuration based on your budget. All core components are sourced from leading industry brands, ensuring performance and protecting your return on investment from the source.
Water well drilling rig series accessories
● Mud pump
● Air compressor
● Drill pipe
● Drilling bit
● Cone bit
● Latent hole impactor
● Air hose
Technical parameter
|
Drilling Diameter (mm) |
140-325 |
Rotary Torque (N・m) |
6900-9700 |
|
Drilling Depth (m) |
350 |
Lifting Power (t) |
24 |
|
Drill Mast Stroke (m) |
6.6 |
Diesel Engine Power (KW) |
91 |
|
Drill Pipe Diameter (mm) |
89-102 |
Travel Speed (km/h) |
2.5 |
|
Working Pressure (MPa) |
1.7-3.3 |
Uphill Angle (Max) |
30 |
|
Air Consumption (m³/min) |
17-35 |
Size (m) |
5.2×2×2.3 |
|
Rotary Speed (rpm) |
45-115 |
Weight (T) |
7.8 |
Note: The product is continuously improved. If the above parameters are changed, please refer to the actual product.
Our Services
End-to-End Project Support
With over 15 years of industry expertise, we provide comprehensive support throughout your project lifecycle — from equipment selection and production line customization to supply chain optimization and post-installation refinement.
Integrated Solutions & Training
We deliver complete construction methodologies and equipment operation training, alongside tailored solutions in cost budgeting, schedule acceleration, quality control, and safety management — ensuring projects are executed efficiently and reliably.
Responsive After-Sales System
Our service team offers full-cycle support, prioritizing rapid response, technical proficiency, and a client-focused attitude to keep your operations running smoothly.
Flexible Customization
Leveraging our adaptable production lines, we empower you to customize your rig — including mold design, drive type, component upgrades, housing material, exterior color, and branding.
Efficient Spare Parts Supply
We maintain a well-stocked parts warehouse to ensure the timely supply of critical wear parts, helping to minimize your equipment downtime and shorten maintenance cycles.
Global Logistics & Delivery
We ship worldwide by sea, land, or air, and handle complex processes such as customs clearance and final-mile delivery — so you receive your equipment seamlessly, anywhere.
